Model HB0512 HB0812 HB1012 HB1512 HB1524 AC Input AC input voltage 220V/110V Input voltage range 220V(145-275VAC±3V) Input frequency 50/60Hz±5% AC Mode Output Output rated power 400W 640W 800W 1200W 1200W AC Mode output voltage The Same As Input Voltage AC Mode output frequency The Same As Input Frequency Battery Mode Output Battery Mode output voltage 220VAC±10%(110VAC±10%) Battery Mode output frequency 50HZ or 60HZ±1% Battery Mode output wave Pure Sine Wave Battery & Charging Battery type Lead Acid Battery/water Battery/lithium Battery Battery voltage 12V 24V Battery charging voltage 13.75VDC 27VDC Max AC charging current 8A 13A 18A 30A 15A Battery charging voltage range 150-280VAC System Operation Transfer time ≤10ms Load peak ratio (MAX)3:1 ECO Mode(w) 6W 8W 9W 11W 12W Display & Alarm Protection Overload /Short circuit/Low voltage/Battery reverse connection protection Status display AC voltage/AC frequency/Output frequency/Battery voltage/Load current Audible alarm Low battery protection buzzer long beep Low battery buzzer every second Overload buzzer long Environmental Conditions Working temperature 0°C~40°C Storage temperature -15°C~45°C Relative temperature -10°C~90°C No condensation Noise ＜45dB Mechanical Dimention(mm) 300*144*213 Net weight (kg) 6.5 6.9 7.8 8.59 9.5
Model HB0512 HB0812 HB1012 HB1512 HB1524 AC Input AC input voltage 220V/110V Input voltage range 220V(145-275VAC±3V) Input frequency 50/60Hz±5% AC Mode Output Output rated power 400W 640W 800W 1200W 1200W AC Mode output voltage The Same As Input Voltage AC Mode output frequency The Same As Input Frequency Battery Mode Output Battery Mode output voltage 220VAC±10%(110VAC±10%) Battery Mode output frequency 50HZ or 60HZ±1% Battery Mode output wave Pure Sine Wave Battery & Charging Battery type Lead Acid Battery/water Battery/lithium Battery Battery voltage 12V 24V Battery charging voltage 13.75VDC 27VDC Max AC charging current 8A 13A 18A 30A 15A Battery charging voltage range 150-280VAC System Operation Transfer time ≤10ms Load peak ratio (MAX)3:1 ECO Mode(w) 6W 8W 9W 11W 12W Display & Alarm Protection Overload /Short circuit/Low voltage/Battery reverse connection protection Status display AC voltage/AC frequency/Output frequency/Battery voltage/Load current Audible alarm Low battery protection buzzer long beep Low battery buzzer every second Overload buzzer long Environmental Conditions Working temperature 0°C~40°C Storage temperature -15°C~45°C Relative temperature -10°C~90°C No condensation Noise ＜45dB Mechanical Dimention(mm) 300*144*213 Net weight (kg) 6.5 6.9 7.8 8.59 9.5
