Uninterruptible Power Supply 6KVA 4800w Line Interactive UPS 220V Pure Sine Wave No Break UPS System

Share to:

Uninterruptible Power Supply 6KVA 4800w Line Interactive UPS 220V Pure Sine Wave No Break UPS System

Tips:
Samples can be sent for testing;
Minimum order quantity (MOQ) ≥5 Pieces;
Feature:
With Toroidal Transformer
Higher Efficiency
Lower Consumption

Availability:



Inquiry

Model:
CYE6K
Brand:
Techfine

Feature

* With Battery Over Discharge And OverCharge Protection,Expand The Battery Life.

* Output short-circuit protection,Battery low & high voltage protection,The UPS From Wrong Operations.

* Long back up design, able to last 24 hours.* Adopt CPU design, computer interface, have self detection function.

* With three-level lightning protection, multi protection of your equipment.

* High Standard Level 3 Lightning Protection Ensure Your Equipments Under Fully Protect.

Application

1. Departmental servers

2. Small LAN

3. Workstation

4. IPO

5. Small medical devices

6. Small precision electronic instruments

7. Enterprise Server

8. Enterprise Lan

9. High-end servers

10. Network Equipment

11. Data center room

12. Sophisticated electronic equipment

Line interactive UPS Application-1

Line interactive UPS Application-3

Line Interactive Sine Wave Ups 6kva Ups 6kva Ups Power Supply ups for air conditioner online ups 3kva ups power supply back up

Model	CYE3K(S)
Phase	Single-phase
Capacity	3000VA/2400W
Input
AC Mains Input Voltage	145-280VAC
Input Frequency Range	50Hz/60Hz
Power Factor	100% load ≥ 0.98
Output
Output Voltage	220 ± 10%
Surge Ratio	3:01
Harmonic Distortion	≤3% THD(linear load)
Transfer Time	≤8ms
Waveform	Pure sine wave
Battery
Standard Model Battery Type	12V 7AH
Standard Model Battery Quantity	6
Standard Model Charging Current	1.5A(Max)
Long Run Model Battery Type	Depend on requirments
Long Run Model Battery Quantity	8
Long Run Model Charging Current	8A(Adjustable)
Appearance
LED Or LCD Display	Load level, battery capacity, AC Mode, battey mode, bypass mode, fault indication
Environment
Noise(dB)	< 40dB at one meter distance
Control Management	Smart RS-232/USB,Optional SNMP

Model	CYE3K(S)
Phase	Single-phase
Capacity	3000VA/2400W
Input
AC Mains Input Voltage	145-280VAC
Input Frequency Range	50Hz/60Hz
Power Factor	100% load ≥ 0.98
Output
Output Voltage	220 ± 10%
Surge Ratio	3:01
Harmonic Distortion	≤3% THD(linear load)
Transfer Time	≤8ms
Waveform	Pure sine wave
Battery
Standard Model Battery Type	12V 7AH
Standard Model Battery Quantity	6
Standard Model Charging Current	1.5A(Max)
Long Run Model Battery Type	Depend on requirments
Long Run Model Battery Quantity	8
Long Run Model Charging Current	8A(Adjustable)
Appearance
LED Or LCD Display	Load level, battery capacity, AC Mode, battey mode, bypass mode, fault indication
Environment
Noise(dB)	< 40dB at one meter distance
Control Management	Smart RS-232/USB,Optional SNMP
