| Model | 40415 | 60415 | 80415 | 100415 |
| System voltage | 12V/24V/36V/48V(adaptive) |
| Rated current | 40A | 60A | 80A | 100A |
| Charging mode | MPPT maximum power point tracking |
| Applicable battery type | Sealed maintenance-free lead-acid battery, the default, colloidal lead-acid battery, the opening of the lead-acid battery can also customize the parameters for other types of battery charging) |
| Charging mode | Three stages: constant current, constant voltage, floating charge |
| PV input the maximum open circuit voltage（VOC） | DC150V(maximum temperatures) DC138V（25℃standard temperature under |
| Start time | ≤10s |
| Dynamic response recovery time | ≤500us |
| Static power consumption | ≤4W | ≤8W |
| Tracking efficiency | ≥99.5% |
| Maximum conversion efficiency | ≥98% |
| Controller system to identify operating voltage range | 8 to 64V |
| Maximum power point operating voltage range | 12V system | 20 to 150VDC |
| 24V system | 36 to 150VDC |
| 36V system | 48 to 150VDC |
| 48V system | 64 to 150VDC |
| Rated Charge Power | 12V | 540W | 800W | 1040W | 1300W |
| 24V | 1080W | 1600W | 2080W | 2600W |
| 36V | 1620W | 2400W | 3120W | 3900W |
| 48V | 2160W | 3200W | 4160W | 5200W |
| 96V |
|
|
| Load voltage | With the battery voltage |
| Rated load current | 40A |
| Load control mode | Normally open normally closed mode/control mode/light control mode |
| Load undervoltage protection | Default 10. 5V*N, N is the cell number of adjustable parameters |
| Cooling mode | Air-cooled |
| Display mode | High definition LCD backlight display |
| Protection function | Input and output over-voltage protection, input and output anti-reverse protection machine over temperature protection, overload current protection |
| Temperature compensation coefficient | A 3mV/℃/2V |
| Communication | RS485 |
| Operating ambient temperature | 20℃～+50℃ |
| Storage temperature | 40℃～+70℃ |
| Noise | ≤50dB |
| Humidity | 0 to 90%RH |
| Altitude | 0 to 3000M |
| Body size(mm) | 219*260*110 | 275*348*109 |
| Net weight（KG）for reference only | 2.8 KG | 4.6 KG | 5.2 KG |
