3KVA 12V High frequency online UPS 3000W uninterrupted power supply

Tips:
Samples can be sent for testing;
Minimum order quantity (MOQ) ≥5 Pieces;
Feature:
Max 12 A big charge current
1.0 output power factor
Up to 95.5% high efficiency

Availability:



Inquiry

Model:
CQ3K
Brand:
Techfine

Feature：

Pure sine wave output, online zero conversion time
Wide input frequency range adjustable from 40-70HZ
Output short circuit protection and overload protection
Full-time lightning protection, noise and surge protection
The LCD screen is to display the status parameters at a glance
The RS232 communication interface is applied
Double-sided circuit board design with higher safety and reliability
Various common technical parameters can be set on the panel

Applications：

UPS场景图-4 UPS场景图-3 UPS场景图-2 UPS场景图-1

3kva Ups 3000w Uninterrupted Power Supply 3kw Online Ups 3kva High Frequency Ups ups for air conditioner ups inverter pure sine wave 1000w

Models		CQ3K (S)
Phase		Single-phase
Capacity		3KVA /3KW
Input
Voltage range		110 - 300VAC
Frequency range		50HZ/60HZ
Power factor		1
Output
Output voltage		220VAC±1% (208, 220, 230, 240 adjustable on LCD screen), 110VAC±1% Optional
Frequency range (battery mode)		50 Hz （60HZ selectable）± 0.25 Hz
Transfer		0ms
time
Wave form		Pure sine wave
Battery
Standard	Battery model	12V / 7AH（Standar) 12V /9AH（Optional)
	Quantity/DC Voltage	6PCS/72VDC
	Max. charging current	1.0A (Maximum)
Long-run	Battery model	Depends on the users
	DC Voltage	96VDC
	Max. charging current	1A, 2A ,3A, 4A, 5A, 6A, 7A, 8A, 9A, 10A, 11A, 12A adjustable
LCD or LED display		Load size, battery capacity, mains mode, battery mode, bypass mode, fault indication
Control management		Smart RS-232、SNMP optional

Models		CQ3K (S)
Phase		Single-phase
Capacity		3KVA /3KW
Input
Voltage range		110 - 300VAC
Frequency range		50HZ/60HZ
Power factor		1
Output
Output voltage		220VAC±1% (208, 220, 230, 240 adjustable on LCD screen), 110VAC±1% Optional
Frequency range (battery mode)		50 Hz （60HZ selectable）± 0.25 Hz
Transfer		0ms
time
Wave form		Pure sine wave
Battery
Standard	Battery model	12V / 7AH（Standar) 12V /9AH（Optional)
	Quantity/DC Voltage	6PCS/72VDC
	Max. charging current	1.0A (Maximum)
Long-run	Battery model	Depends on the users
	DC Voltage	96VDC
	Max. charging current	1A, 2A ,3A, 4A, 5A, 6A, 7A, 8A, 9A, 10A, 11A, 12A adjustable
LCD or LED display		Load size, battery capacity, mains mode, battery mode, bypass mode, fault indication
Control management		Smart RS-232、SNMP optional
