Techfine 5kw 5000w All in One Off Grid Hybrid Mppt Solar Power High Frequency Inverter with Battery

Share to:

Techfine 5kw 5000w All in One Off Grid Hybrid Mppt Solar Power High Frequency Inverter with Battery

Name: Techfine 5kw 5000w All in One Off Grid Hybrid Mppt Solar Power High Frequency Inverter with Battery
Brand: Techfine
SKU: 541935228
Rating: 5.0 (90 reviews)

Minimum order quantity (MOQ) ≥5 Pieces;
Samples can be sent for testing;

Feature：

Power factor 1.0, high working efficiency
Lightweight design, save freight
Parallel function is optional, convenient for expansion
Easy to set. You can set parameters on the LCD screen

Built-in 60A/100A MPPT, maximum PV input up to 500V

Pure sine wave output, suitable for a variety of loads, with load stability

Rated Capacity:	5000W
Availability:



Inquiry

Model:
GA
Brand:
Techfine
Code:
GA5048MH

Feature

Slim body, convenient installation and transportation

Communication option, external WIFI, supervise at any time

Parallel function up to maximum 9 units, enlarge more loads

High precision of output voltage, ±5%, take care of your appliances

Application

pexels-binyamin-mellish-1396122 pexels-curtis-adams-16641323

pexels-max-rahubovskiy-6436752 pexels-matheus-bertelli-13871260

High Frequency Solar Inverter With Battery MPPT High Frequency Solar Inverter Off Grid Hybrid Solar Inverter 5000w Hybrid Solar Inverter Lightweight Solar Inverter 48v Hybrid Solar Inverter All in One Solar Inverter off grid solar inverter solar hybrid inverter mppt solar inverter

GA series High frequency inverter data sheet
Model		GA3024MH	GA5048MH
Input	Phase	L+N+PE
	Nominal Voltage	208/220/230/240VAC
	Voltage Range	154-264VAC±3V（Normal Mode) 185-264VAC±3V（UPS Mode）
	Frequency Range	50Hz/60Hz(Adaptive)
Output	Rated Power	3000W	5000W
	Output Voltage(AC)	208/220/230/240VAC±5%
	Output Frequency	50/60Hz±0.1%
	Waveform	Pure sine wave
	Transfer Time( Optional)	10ms for computer , 20ms for home appliances
	Peak power	6000VA	10000VA
	Overload	Battery Mode： 1min@102%~110% Load 10s@110%~130% Load 3s@130%~150% Load 200ms@>150% Load
	Peak efficiency (battery mode)	>94%	>94%
Battery	Rated voltage	24Vdc	48Vdc
	Constant voltage charging voltage (Optional)	28.2Vdc	56.4Vdc
	Floating charge voltage (Optional)	27Vdc	54Vdc
charger	PV charging method	MPPT	MPPT
	PV max input power	3500W	5500W
	MPPT tracking range	120~430Vdc	120~430Vdc
	Max PV input voltage	450Vdc	450Vdc
	Max PV charging current	60A	80A
	Max AC charging current	60A	80A
	Max charging current	60A	80A
Display	LCD display	Operating mode/load/input/output, etc.
Communication port	RS232	5PIN/Pitch2.0mm, baud rate 2400
	Expansion & configuration port	2×5PIN/Pitch2.54mm, lithium battery BMS communication card, WIFI card, dry contact card, etc.
	Parallel interface	No	Yes
Environmental parameters	Operating environment temperature	0~40℃
	Operating environment humidity	20%~95%（Non condensing）
	Storage temperature	-15~60℃
	Altitude	The altitude should not exceed 1000m, derating above 1000m, up to 4000m, refer to IEC62040
	noise	≤50db
Certifications		EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1
